High Speed Data Acquisition Card
High Speed Data Acquisition Card
Smartgiant offers a high-speed multi-channel data acquisition system and PCIe high-speed acquisition cards suited for advanced testing and measurement applications. Key features of their high-speed data acquisition cards include:
A dual-channel design with up to 500 MSPS sampling rate and 14-bit resolution, enabling capture of intricate signal details.
An analog input bandwidth up to 200 MHz, effective for monitoring fast-changing signals.
Equipped with 2G DDR4 RAM and 16G eMMC storage for substantial data collection.
Trigger input/output for precise synchronization of measurements.
PCIe 3.0 x8 interface with FPGA-based processing (Xilinx Kintex UltraScale).
Customizable hardware, FPGA, and software to tailor the solution.
Supports high-speed data capture with exceptional accuracy for industries like automotive, telecommunications, and scientific research.
Additionally, they have a product called the SG1227 PCIe High-Speed Acquisition Card featuring:
8-bit dual-channel digitizer,
Sampling rates up to 5 GS/s,
Analog bandwidth up to 500 MHz,
Customization and stringent production/testing standards.
Smartgiant emphasizes delivering high-quality, customizable data acquisition solutions with global availability including markets like East Asia, the US, South Africa, and Australia.
For detailed specifics, product customization, or SDK/software support, Smartgiant provides solutions through comprehensive customer support and partnerships.
In summary, Smartgiant’s high-speed data acquisition cards are advanced, versatile, and suitable for demanding real-time signal capture in a wide range of professional applications.
If you want, I can provide more product model details, pricing, or technical specifications on Smartgiant’s high-speed data acquisition offerings.
Get Test & Measurement Technologies & Solutions!
Specializing in FPGA-based Control, Processing, and Scceleration technologies
High Speed Data Acquisition Card Boost Profit – Consider other products?
Archon-Automated Test Manager
- Powerful automated test development and management application software, which can quickly develop, deploy, and manage automated test and verification systems.
- Archon can be used to develop, execute, and deploy test cases and test plans, and extend the functionality of the system by developing plug-ins on Archon.
- Archon provides extensible plug-ins for report generation, database recording, and connections with other enterprise systems.
Waveform Generator (Plug-in)
• Resolution: 16 Bits
• Refresh Rate: 125 MHz
• FSK/ASK signal generation
Measurement and Control Board
• Industrial design: compliant with IEC standards
• A wide range of I/O resources (44 channels)
• Stable, reliable, and precise AFE signal conditioning
• 24-bit ADC high-resolution measurement performance
• A wide range of communication interfaces: 1*100M Ethernet upstream port (Modbus-TCP) and 8*RS485 downstream ports (Modbus-RTU)
• Supports channel isolation: digital-to-ground isolation
• Supports fault detection
• Customizable hardware interface, channel quantity and dimensions
PCB Probe Inspector
• High accuracy: Adopting a high-precision linear motor module, the equipment achieves positioning accuracy of up to ±5 um of on the X and Y axes.
• FCT/ICT Test
• PCB AOI Inspection
Test Bench
- High-performance processor, adopting ZYNQ-7000 series processor, dual-core ARM Cortex-A9, with main frequency up to 866 MHz.
- High precision multimeter, resistance measurement 0 Ω to 100 MΩ, voltage measurement -60 V to 60 V, current measurement 0 to 3 A.
- Audio analyzer, supporting differential input/output and single ended input/output functions, with a sampling rate of up to 192 kps, and capable of measuring signal amplitude, frequency, THD, THD+N.
- Signal generator, supporting output of sine wave, square wave, triangular wave, up to 1 MHz output.
- Oscilloscope module, supporting ±0.9 Vpp input, up to 5 MHz bandwidth, 125 MHz sampling rate.
- Support multi-channel output power supply, multi-function serial port communication, DO output, button simulation, multi-channel load current switching measurement.
- Internal integrated relay switching matrix, RF switch, up to 18 GHz RF signal switching.
Power Monitor
- 8V-14V adjustable output voltage, maximum continuous output current 8A.
- Real-time collection of voltage, current and power data, which can be displayed graphically through software.
- Support power supply data acquisition of external power supply device for external device power analysis.
- Support using multiple devices simultaneously to enable parallel monitoring.
- Support USB and network communication modes and localized data storage function.
- Capable of power-on self-inspection and multi-faceted protection, including overvoltage, undervoltage, overcurrent and over-temperature protection.
