Over the last few years, our factory continues to lead the way integrated advanced technologies, ensuring high-quality to excellence. We are looking forward to cooperating with you and providing our best services for you, as well as our Surveillance camera ai, FPGA Control Modules,Test and Measurement Instruments.

The Rockchip RV1126 and RV1106 are both System-on-Chip (SoC) platforms designed specifically for AI-powered surveillance camera applications, commonly used in security, smart city, and industrial monitoring scenarios.

Rockchip RV1126 Surveillance AI Camera Modules

  • Processor: Quad-core ARM Cortex-A7 CPU (up to 1.5 GHz) paired with an integrated Neural Processing Unit (NPU) offering up to 2.0 TOPS for real-time AI inference (e.g., face recognition, human detection).

  • Image Processing: Supports high-resolution sensors such as the Sony IMX335 (5MP) and IMX415 (8MP), with the ability to encode 4K video at 30fps and support for H.264/H.265 compression. It features a high-end ISP (Image Signal Processor) for 14MP photos, multi-level noise reduction, and wide dynamic range (up to 120 dB HDR).

  • AI Features: Enables intelligent analytics such as face detection, intrusion/line-cross detection, people counting, loitering, and advanced motion detection with a focus on filtering non-human movements and minimizing false alarms.

  • Network and Storage: Offers PoE (Power over Ethernet), audio input/output, SD card backup (up to 512 GB supported on some modules), and ONVIF compatibility for easy integration into video management systems.

  • Other Features: Supports remote monitoring via Android/iOS apps, internal microphones, advanced privacy masking, alarm inputs/outputs, and robust IP67-rated (weatherproof) housings.

  • Software Frameworks: Compatible with AI frameworks such as TensorFlow, PyTorch, and ONNX for custom model deployment.

Rockchip RV1106 Surveillance AI Camera Modules

  • Processor: Positioned as a cost-effective, lower-power version optimized for edge AI tasks in budget-oriented surveillance cameras. It features an ARM Cortex-A7 core and a modest NPU for essential AI analytics.

  • Imaging: Typically supports up to 4MP sensors, offering 1080p real-time video encoding (H.264/H.265), and basic ISP functions for noise reduction and digital wide dynamic range.

  • AI Functionality: Focuses on basic AI features such as motion detection, simple object/human filtering, and privacy masking—ideal for entry-level surveillance where advanced analytics are less critical.

  • Integration Capabilities: Maintains low power consumption and reduced thermal output for compact and affordable deployments, with network and storage interfaces similar to RV1126 but fewer advanced features.

  • Use Case Fit: Appropriate for basic monitoring, home security, or large-scale IoT deployments where cost and efficient operation are prioritized over AI complexity.

RV1126 vs RV1106—Key Differences

Feature RV1126 RV1106
AI NPU Up to 2.0 TOPS Lower, basic AI (≤ 0.5 TOPS)
Sensor Support Up to 14MP (4K @ 30fps) Up to 4MP (1080p @ 30fps)
Video Processing Advanced ISP, 120dB HDR Basic ISP, digital WDR
Target Application Advanced AI surveillance Entry/basic surveillance
Typical AI Tasks Face/people detection, analytic Motion detection


In summary:

  • RV1126 is ideal for advanced smart AI security cameras requiring high-resolution imaging, powerful onboard analytics, and rich integration options for smart city or enterprise surveillance.

  • RV1106 is best-suited for cost-effective, mass-market surveillance applications focusing on essential AI features and efficient operation.

Both SoCs are central to next-generation AI security cameras, enabling powerful edge processing, minimizing network dependency, and providing scalable, real-time surveillance analytics.

Smartgiant Technology is dedicated into the market to providing premium video camera ai and service all over the world. We keep on with our business spirit of quality, skilled operation is our work, putting you first is our mission. With your kind help, we believe that we can create a bright future with you together. Call or E-mail us your specifications or inquiries right now.





Get Test & Measurement Technologies & Solutions!

Specializing in FPGA-based Control, Processing, and Scceleration technologies




Video Camera Ai Boost Profit – Consider other products?





Data Logger (Plug-in)

• Resolution: 32 Bits

• Sampling Rate: 250 kSPS

• Recording dual-channel voltage inputs simultaneously and continuously

• Uploading raw data to the PC in real-time

Read More »
LCR BOX-2

LCR Meter Box

  • Supports three testing excitation modes: open-circuit voltage, constant voltage, and constant current.
  • Supports dual-mode measurement of LCR (inductance, capacitance.resistance) and DCR (DC resistance)
  • The maximum excitation level supported is 1 Vrms  with DC bias capability.
  • Supports Broadband measurement range from 20 Hz to 2 MHz.
  • The basic impedance measurement accuracy is better than 0.1%.
  • Up to 19 parameter measurements.
  • Measurement speed of up to 5 ms.



Read More »



Video Camera Ai Cut Down Cost – View Other Pages




sDAQ

What is DAQ?

Part 1: Understanding DAQ – The Essential Tool for Data Acquisition In today’s fast-evolving world of technology, data has become

Read More »

Horus AI Camera

Horus is a set of software and hardware platforms customized for AI cameras. With an RV1126 quad-core processor, these platforms

Read More »

Daq Board

  Daq Board Smartgiant Technology is dedicated into the market to providing premium daq board and service all over the

Read More »



More About Video Camera Ai


Greetings from Smartgiant Technology, have a look at the most top-quality video camera ai here! Smartgiant Technology has a long history and experience of providingvideo camera ai, which means we are reliable and masterful. Over the years, our presence in this market has allowed us to amass numerous employees, run a sizable factory, and maintain a robust monthly production capacity. Our video camera ai are unique. We prioritize quality by enforcing strict testing standards, following standardized production protocols, and implementing a comprehensive quality management system to oversee our video camera ai. Moreover, as a masterful, we have a wide range of experience of video camera ai and have gain great reputation. Our cooperative network extends to partners from lots of countries. The main sales regions we cover span almost every part of the world. We always believe that your request is our command!If you are looking for a reputable partner, consider us right now!
