In recent times, our factory encourages creative thinking and innovative technologies, ensuring high-quality to excellence. We are eager to cooperate with foreign companies which care much on the high standard, reasonable prices, effective capability and superior service. The Field Programmable Gate Array will supply to all over the world, such as East Asia, South Africa, Canada, Western Europe, etc. We’ve been honest and open up, innovation and integrity guide our path, we survive by focusing on what customers want. To ensure your satisfaction, we contine to enhance production quality and effeciency, all customized orders are acceptable, each product has met the standards required for professional certification. We are looking forward to cooperating with you and providing our best services for you, as well as our Field Programmable Gate Array, FPGA Control Modules,Test and Measurement Instruments. We strongly think that we will do superior and far better. We glance ahead on your pay a visit to and developing trustworthy and long-term standing relationship. Smartgiant Technology is dedicated into the market to providing premium Field Programmable Gate Array and service all over the world.
Get Test & Measurement Technologies & Solutions!
Specializing in FPGA-based Control, Processing, and Scceleration technologies
Field Programmable Gate Array Boost Profit – Consider other products?
3.75 GHz RF Acquisition and Playback Module
• Main Controller: XCKU040-2FFVA1156I chip form Xilinx UltraScale series
• RF Performance: Supports dual channels, with 2-lane TX channels supporting 10MHz to 6GHz frequency output; 2-lane RX high-speed adjustable data channels offering frequency input from 10MHz to 8GHz
• Extensive Expansion Interfaces: 2 HPC FMC expansion interfaces, 2 Gigabit Ethernet interfaces, 2 JTAG download and debugging interfaces and 1 M.2 socket interface
• ADC Performance: 14-bit resolution, 3 GSPS sampling rate
• DAC Performance: 16-bit resolution, 12.6 GSPS sampling rate
• Customization: offer customization services for the hardware interfaces and functions of the FPGA development board, along with ADC and DAC submodule
Bluetooth Tester
• Support Basic Rate，EDR and low energy RF measurements
• Compliant with Bluetooth 1.2, 2.0 and 2.1, 3.0+HS, 4.0, 5.0 and 5.3 core specification
• Initialization and control of test devices through USB or UART HCI control port
Test Bench
- High-performance processor, adopting ZYNQ-7000 series processor, dual-core ARM Cortex-A9, with main frequency up to 866 MHz.
- High precision multimeter, resistance measurement 0 Ω to 100 MΩ, voltage measurement -60 V to 60 V, current measurement 0 to 3 A.
- Audio analyzer, supporting differential input/output and single ended input/output functions, with a sampling rate of up to 192 kps, and capable of measuring signal amplitude, frequency, THD, THD+N.
- Signal generator, supporting output of sine wave, square wave, triangular wave, up to 1 MHz output.
- Oscilloscope module, supporting ±0.9 Vpp input, up to 5 MHz bandwidth, 125 MHz sampling rate.
- Support multi-channel output power supply, multi-function serial port communication, DO output, button simulation, multi-channel load current switching measurement.
- Internal integrated relay switching matrix, RF switch, up to 18 GHz RF signal switching.
Zynq7000 Series
• Powered by: XilinxXC7Z020 / 010 / 007S
• Modular Design: enables flexible integration
• Compact Build: allows seamless embedment
• High Performance: FPGA + ARM + High-speed I/O
• Comprehensive FPGA IP core library
Data Logger (Plug-in)
• Resolution: 32 Bits
• Sampling Rate: 250 kSPS
• Recording dual-channel voltage inputs simultaneously and continuously
• Uploading raw data to the PC in real-time
PLC Measurement & Control System Upgrade and Replacement System
• Stable, reliable, and precise AFE signal conditioning
• Up to 32-bit ADC (Analog-to-Digital Converter)
• Digital signal processing on multiple platforms such as MCU, ARM, FPGA, DSP, and GPU
• Multi-dimensional surface fitting and calibration
