Smart Data Acquisition (sDAQ)
- Portable modular design
- Industrial-grade design with high performance and reliability
- Supports channel isolation and synchronized measurements
- Offers customized services
Overview
The sDAQ is a portable, modular device designed for acquiring and processing both digital and analog signals. It can handle a variety of measurements, including digital I/O, voltage, current, temperature, strain/bridge, general analog inputs, as well as audio and vibration data. The sDAQ comprises sensors, DAQ measurement hardware, and management software, making it ideal for various applications in industrial settings, scientific research, and field data collection. It offers robust support for test, measurement, and smart factory decision-making through reliable support for testing and measurement operations.
Application Scenarios
• Automotive & Transport
• Power & Energy
• Wireless Communications & Infrastructure
• Environmental Monitoring
• Healthcare
• Food & Beverage
Specifications
I/O Module |
Range |
Input Voltage |
resolution |
Single-ended/Differential |
Sourcing /Sinking |
Sampling Rate/Update Rate |
Number of Channels |
Isolation |
Synchronous Measurement |
Analog Voltage Input (AIV) |
±10V |
- |
16 bits |
Single-ended |
- |
200k SPS/ch |
8 |
Channel to Ground |
Channel Sync |
Analog Current Input (AII) |
±25mA |
- |
16 bits |
Single-ended |
- |
200k SPS/ch |
8 |
Channel to Ground |
Channel Sync |
Analog Voltage Output (AOV) |
±10V |
- |
16 bits |
Single-ended |
- |
100k SPS/ch |
8 |
Channel to Ground |
Channel Sync |
Analog Current Output (AOI) |
25mA |
- |
16 bits |
Single-ended |
- |
100k SPS/ch |
8 |
Channel to Ground |
Channel Sync |
Static Digital Input (DI) |
- |
0~24V |
- |
Single-ended |
Sourcing /Sinking |
10k Hz |
32 |
Channel to Ground |
Channel Sync |
Static Digital Output (DO) |
- |
0~24V |
- |
Single-ended |
Sourcing /Sinking |
10k Hz |
32 |
Channel to Ground |
Channel Sync |
Dynamic Digital Input (DI) |
- |
0~5V |
- |
Single-ended/Differential |
- |
20M Hz |
32 |
Channel to Ground |
Channel Sync |
Dynamic Digital Output (DO) |
- |
0~5V |
- |
Single-ended/Differential |
- |
20M Hz |
32 |
Channel to Ground |
Channel Sync |
Counter/Timer |
- |
0~5V (differential) 0-24V (single-ended) |
32 bits |
Single-ended/Differential |
- - |
5M Hz |
8 |
Channel to Ground |
Channel Sync |
Thermocouple Temperature Input |
±80mV |
- |
24 bits |
- |
- |
100 SPS/ch |
8 |
Channel to Ground |
Channel Sync |
RTD Temperature Input |
4k ohm |
- |
24 bits |
- |
- |
400 SPS/ch |
8 |
Channel to Ground |
Channel Sync |
Sound & Vibration Input |
±5V/30V |
- |
24 bits |
- |
- |
102.4k SPS |
4 |
Channel to Ground |
Channel Synchronous |
Strain/Bridge Input |
±25mV/V |
- |
24 bits |
- |
- |
200k SPS |
4 |
Channel to Ground |
Channel Synchronous |
